Wanda F480G-power small crane lifting 480 kg
Model: F480G
Price RMB: 4800 鍏
Technical parameters:
Lifting capacity: 480 kg single hook
Rated voltage: 220v
Rated power: 2.0KW
Rated frequency: 50HZ
Rope length: 30 m
Factory rope diameter: 5 mm
Weight: 110 kg
Indoor installation height: 1.5M-3.2M
Furthest out of the window length: 0.95M
Retracted window within the shortest length: 0.65M
The minimum working space: 0.65M
Maximum weight: 1000 kg
Maximum lifting height: 200M
Bracket Weight: 60 kg
The product patent number: 200520008736.X
The machine installation diagram
Cost level: Five Star
Scope:
Applicable to a support surface (also used for indoor outdoor) spaces down lifting materials, and used in combination with the attached frame outdoor works to achieve the effect of the outdoor type. Can also be used in combination with a large engineering scaffold.
The main features
1, easy to carry
This product is small, light weight, small size and compact structure, easy to carry.
2, easy to install,
The power unit placed near a window (or balcony), Office of the bracket assembly parts, and insert it into the hole base power plant, five minutes to install.
3, lifting speed, 4 seconds to enhance one meter, 10-storey three minutes you can play back and forth, equipped with "special tools" being lifted at an alarming rate, and the greater the advantage of the higher floors
4, for a wide range
Using 220-volt single-phase power supply for decoration companies, lifting companies, installation companies, moving companies, workshop, repair departments, storage warehouse, and other industries and households.
As well as extensive use of premises, can be installed in addition to households, can also be installed on the roof, you can use hand corner rack mounted on large projects the site can also be transported in small buildings instead of gantry crane
Works. Can install protective nets, billboards, roof waterproof cast also do engineering; able to repair the pump workover can store fruits, drying grain ......
5, easy to operate, safe and reliable.
One hour you can learn how to operate the machine, according to the instructions when operating outside appearance, lifting objects can travel across stopper and toggle switch, immediately cut off the power supply to ensure safe operation.
|
